Our Thermostatically Universal Ovens are double
walled and the exterior is constructed from mild steel finished in powder
coated paint. These are available with various options such as air
circulating fan, electronic digital indicator cum temp controller an instead
of l shape thermometer.
Inner Chamber Sizes :-
W x H x D
- Thermostatically Universal Oven BS:2648, 1881, 598, 1377 & 1924.
- Double walled, exterior is constructed from M.Steel finished in
powder Coated Paint.
- With glass wool insulation between two walls. Inner wall made of
Aluminium / Stainless Steel. Heating elements are placed in ribs of the
bottom & sides for uniform heating having temp, range 5°C above
ambient to 250°C .
- Air ventilator adjustable fitted on both sides provided with L shape
thermometer fixed at front of the oven . temp, is controlled by
thermostat with an accuracy of ±1°C fitted with main switch,
pilot lamp, temp, controlling knob and supplied with perforated shelves
and working on 220V 1 phase 50Hz A.C.
- 305 x 305 x 305mm
- 355 x 355 x 355 mm
- 455 x 455 x 455 mm
- 455 x 605 x 455 mm
- 605 x 605 x 605 mm
- 605 x 905 x 605 mm
- 905 x 905 x 905 mm
- Air Circulating Fan
- Electronic Digital Indicator cum temp Controller
- Instead of L Shape Thermometer.
- NOTE: Any other size available on request.
Our quality range of Curing Tank is catering to the
requirements of diverse applications in defense, automobile, research and
development activities and construction industries. These are available in
various sizes as per the clients specific requirements.
- Accelerated Curing Tank
The Tank has been designed to accommodate 150 mm/70.6 mm cube Moulds &
fully insulated, complete with hinged lid, heater, Digital temperature
Controller & Circulated Pump.
Provision of two removable racks allowing free circulation of water
around each Mould. The pump, drain valves and electrical equipment are
housed in a compartment located at one end of the tank.
The tank is heated by immersion heater under normal conditions the
Temperature is controlled at 35deg.C or 100 deg.C. +-2deg. These Tanks
are available in various sizes. Curing Tanks are also available with
With our immense domain expertise in the industry,
we have been able to offer a wide range of Hot Plate with rectangular top
250 mm x 300 mm fitted with digital controller-cum-indicator. The column
displacement for single and double stage pumps respectively is fitted with
vacuum gauge with regulator, moisture trap, belt guard cord and plug, To
work on 220 V. A.C. 251ts. /min. & 50 Lts. /min.
We offer B.O.D.Incubator with built in voltage
stabilizer, temperature range 5 deg. to 50 deg.c. with an accuracy of ±
0.5°C. controlled by digital temperature controller cum indicator which
cut off automatically either heating or cooling system when the ambient
temperature increase or decrease from the set temperature of the chamber.
We are offering a wide range of Laboratory Weighing
Balances also known as Field Balances, which is renowned for high end
features such as Battery operated, large LCD display and compact design.
These are available in various capacities as per the clients
- Large LCD Display
- Soft Touch Tack Switch
- Compact Design
- Tare & Hold Facility
- Double Display.
- AC Adaptor also.
- Stamping done by Weight & Measuring Deptt.
- Different capacities like
- 5 Kgs x 0.5gm., 10 Kgs x 1 gm., 15 Kgs x 1 gm.,
- 20 Kgs x 1 gm., 30 Kgs x 2gm.
- 300gm. x 0.01 gm., 600gm. x 0.01 gm. 1 kg x 0.1 gm.
- NOTE : Other Models also available with different weighing
It consists of water bath made of M. steel. Having
the illuminator at rear side. The temperature is controlled by electric
relay. It is supplied with one no. of mercury type thermometer and manometer
It is available in three different options for temp. range such as ambient
to 100ºC, 5°C TO 100 °C and ambient to 150 ºC
Note: Bath can be fitted with P.I. D. controller extra cost.
Following bath size is available.
- Size (L x W x H )
a) 12" x 9" x 12" (To accommodate 4 viscometers)
b) 12" x 12" x 12" (To accommodate 6 viscometers)
c) 18" x 12" x 12" (To accommodate 8 viscometers)
