General Lab Equipments

Our Thermostatically Universal Ovens are double walled and the exterior is constructed from mild steel finished in powder coated paint. These are available with various options such as air circulating fan, electronic digital indicator cum temp controller an instead of l shape thermometer.

Specifications :-

• Thermostatically Universal Oven BS:2648, 1881, 598, 1377 & 1924.
• Double walled, exterior is constructed from M.Steel finished in powder Coated Paint.
• With glass wool insulation between two walls. Inner wall made of Aluminium / Stainless Steel. Heating elements are placed in ribs of the bottom & sides for uniform heating having temp, range 5°C above ambient to 250°C .
• Air ventilator adjustable fitted on both sides provided with L shape thermometer fixed at front of the oven . temp, is controlled by thermostat with an accuracy of ±1°C fitted with main switch, pilot lamp, temp, controlling knob and supplied with perforated shelves and working on 220V 1 phase 50Hz A.C.

Inner Chamber Sizes :-
W x H x D

• 305 x 305 x 305mm
• 355 x 355 x 355 mm
• 455 x 455 x 455 mm
• 455 x 605 x 455 mm
• 605 x 605 x 605 mm
• 605 x 905 x 605 mm
• 905 x 905 x 905 mm

Optional :-

• Air Circulating Fan
• Electronic Digital Indicator cum temp Controller
• Instead of L Shape Thermometer.
• NOTE: Any other size available on request.

Our quality range of Curing Tank is catering to the requirements of diverse applications in defense, automobile, research and development activities and construction industries. These are available in various sizes as per the clients’ specific requirements.
Specifications:

• Accelerated Curing Tank
  The Tank has been designed to accommodate 150 mm/70.6 mm cube Moulds & fully insulated, complete with hinged lid, heater, Digital temperature Controller & Circulated Pump.
  Provision of two removable racks allowing free circulation of water around each Mould. The pump, drain valves and electrical equipment are housed in a compartment located at one end of the tank.
  The tank is heated by immersion heater under normal conditions the Temperature is controlled at 35deg.C or 100 deg.C. +-2deg. These Tanks are available in various sizes. Curing Tanks are also available with cooling arrangement.

With our immense domain expertise in the industry, we have been able to offer a wide range of Hot Plate with rectangular top 250 mm x 300 mm fitted with digital controller-cum-indicator. The column displacement for single and double stage pumps respectively is fitted with vacuum gauge with regulator, moisture trap, belt guard cord and plug, To work on 220 V. A.C. 251ts. /min. & 50 Lts. /min.

We offer B.O.D.Incubator with built in voltage stabilizer, temperature range 5 deg. to 50 deg.c. with an accuracy of ± 0.5°C. controlled by digital temperature controller cum indicator which cut off automatically either heating or cooling system when the ambient temperature increase or decrease from the set temperature of the chamber.

• B.O.D.Incubator
  With built in Voltage Stablizer, Temperature range 5 deg. to 50 deg.c. with an accuracy of ± 0.5°C. controlled by digital temperature controller cum indicator which cut off automatically either heating or cooling system when the ambient temperature increase or decrease from the set temperature of the chamber.

  Double walled, outside made of mild steel, epoxy paint, inside made of stainless steel, 2 air circulating fans, with glass door inside, outer door has magnetic gasket, lock & key, door operated illumination, perforated adjustable shelves made of wire mesh for better air circulation of air in the chamber in lieu of shelves made of sheet metal, Eco-friendly CFC Free refrigerant.
  The unit has a detachable control panel kept on top of the equipment, Wheels for easy mobility.
  Size :- 4CU.FTW455xH610xD410mm 6 CU.FT W 505 x H 830 x D 415mm 10 CU.FT W 570 x H 875 x D 550mm 12 CU.FTW 650 xH 910 xD 605mm

We are offering a wide range of Laboratory Weighing Balances also known as Field Balances, which is renowned for high end features such as Battery operated, large LCD display and compact design. These are available in various capacities as per the clients’ requirements.
Specifications:

• Battery
• Large LCD Display
• Soft Touch Tack Switch
• Compact Design
• Tare & Hold Facility
• Double Display.
• AC Adaptor also.
• Stamping done by Weight & Measuring Deptt.
• Different capacities like
• 5 Kgs x 0.5gm., 10 Kgs x 1 gm., 15 Kgs x 1 gm.,
• 20 Kgs x 1 gm., 30 Kgs x 2gm.
• 300gm. x 0.01 gm., 600gm. x 0.01 gm. 1 kg x 0.1 gm.
• NOTE : Other Models also available with different weighing capacities.

It consists of water bath made of M. steel. Having the illuminator at rear side. The temperature is controlled by electric relay. It is supplied with one no. of mercury type thermometer and manometer stand.
It is available in three different options for temp. range such as ambient to 100ºC, 5°C TO 100 °C and ambient to 150 ºC
Note: Bath can be fitted with P.I. D. controller extra cost.

Following bath size is available.

• Size (L x W x H )
  a) 12" x 9" x 12" (To accommodate 4 viscometers)
  b) 12" x 12" x 12" (To accommodate 6 viscometers)
  c) 18" x 12" x 12" (To accommodate 8 viscometers)
